Over Current Relay (AOC-107)

Features

• Provides reliable protection against over-current conditions.
• Adjustable current setting range: 0.5 to 5 Amps.
• Adjustable time delay: 1 to 10 seconds.
• Operates on 230V AC working voltage.
• Compact and durable design for industrial and commercial use.
• High contact rating for efficient operation under load.

Applications

• Protection of motors, transformers, and other electrical equipment from over-current conditions.
• Industrial and commercial control panels.
• Generator and backup power systems.
• Suitable for HVAC systems, pumps, and compressors.

Technical Specifications

• Working Voltage: 230V AC
• Current Setting Range: 0.5 to 5 Amps
• Time Setting: 1 to 10 seconds
• Contact Rating: 5 Amps
• Frequency: 50 Hz
• Dimensions: 60 x 70 x 110 mm
• Body Material: Flame-resistant plastic housing
• Mounting: Panel or DIN rail
