Star Delta Timer

Features

• Operates on AC: 220V/415V.
• Designed for star-delta motor starter applications.
• Dual changeover contacts (2 NO + 2 NC).
• Time setting range: 6–60 seconds.
• Compact and robust design.
• High accuracy and repeatability.
• Easy to install and configure.

Applications

• Star-delta motor starter control circuits.
• Industrial motor control panels.
• Energy-efficient motor starting.
• Protection of large motors during startup by reducing inrush current.
• Pump and compressor systems.

Technical Specifications

1. Power Supply:

• AC Voltage: 220V / 415V
• Working Voltage: 230 VAC

1. Time Range: 6–60 seconds
2. Contacts:

• 2 NO + 2 NC (Changeover contacts)
• Contact Rating: 5 Amps

1. Operation Mode: Star-delta transition timer
2. Dimensions: 45 x 70 x 110 mm
3. Body Material: Durable and flame-resistant plastic housing
4. Mounting: Panel or DIN rail
