Timer Off Delay/Stopping

Features

• Operates on AC: 110V/220V/415V and DC: 12V/24V.
• Off delay functionality for delayed switching off of loads.
• Adjustable time settings for different ranges:
  • AT-10F: 1–10 seconds
  • AT-30F: 3–30 seconds
  • AT-60F: 6–60 seconds
• Wide input voltage range supported by SMPS power supply (50–300V).
• Compact design for easy installation.
• Reliable performance with high contact rating.

Applications

• Industrial machinery stopping sequences.
• Delayed shutdown of equipment.
• Ventilation fan controls.
• Power-off sequencing in automation systems.
• Conveyor belt stopping controls.

Technical Specifications

1. Power Supply:

• AC Voltage: 110V / 220V / 415V
• DC Voltage: 12V / 24V
• SMPS Input Range: 50–300V

1. Time Settings:

• AT-10F: 1–10 seconds
• AT-30F: 3–30 seconds
• AT-60F: 6–60 seconds

1. Working Voltage: 230V AC / 12V DC
2. Contact Rating: 5 Amps
3. Operation Mode: Off Delay
4. Dimensions: 60 x 70 x 110 mm
5. Body Material: Durable and flame-resistant plastic housing
6. Mounting: Panel or DIN rail
