Cyclic/Priming Timer

Features

• Operates on AC: 110V/220V/415V and DC: 12V/24V.
• Cyclic timing functionality for repetitive operations.
• Adjustable time ranges for both ON and OFF cycles:
  • AT-10C: 1–10 seconds
  • AT-30C: 3–30 seconds
  • AT-60C: 10–60 seconds
  • AT-100C: 10–100 seconds
• High accuracy and reliability.
• Compact, durable, and user-friendly design.
• Suitable for continuous operation.

Applications

• Water pump priming systems.
• Industrial process control.
• Sequential operation of machines.
• Air compressors.
• Periodic activation of alarms or indicators.
• Sprinkler systems and irrigation controls.

Technical Specifications

1. Power Supply:

• AC Voltage: 110V / 220V / 415V
• DC Voltage: 12V / 24V

1. Time Ranges:

• AT-10C: 1–10 seconds
• AT-30C: 3–30 seconds
• AT-60C: 10–60 seconds
• AT-100C: 10–100 seconds

1. Operation Mode: Cyclic (ON/OFF)
2. Operating Temperature: -10°C to 55°C.
3. Contact Rating: Suitable for load switching (commonly 5A at 230V AC).
4. Mounting: Panel or DIN rail.
5. Body Material: Flame-resistant plastic.
